New Asphalt Batch Mixing Plant
Specifications
- Brand
- TADANO,KATO,KOMATSU,CAT,GROVE,
- Origin
- CHINA
New Asphalt Batch Mixing Plant is a Faucets, Mixers & Taps product. Key specs — Brand: TADANO,KATO,KOMATSU,CAT,GROVE,; Origin: CHINA.
Product Description
Detailed Product Description Rated productivity: 60tph, 80tph Mobile asphalt batching plant using twin-horizontal shafts force mixer saves stirring time and makes bitumen wrapping in a high degree. It blade, vane and mixing arms are made of special wear-resisting material and they can work longer.
Material-added gate with double air cylinder is in turning form which saves time and increase the sealing. It consists of dryer drum, burner, central venting, forced mixer, finished silo and three bin feeder for cold aggregates.
1) Rated productivity: 60tph, 80tph 2) Suitable material: bitumen, aggregate 3) Feeder hopper capacity: 1,500kg x 2, 1,600kg x 2 4) Main power: oil burner 153kW, 176kW, coal burner 200kW, 239kW 5) Product temperature: 120~165°C, adjustable 6) Burner: oil, coal and oil 7) Control system: PLC, auto-control and manually, electronic cabin and control panel, touch screen, control room Other mdoel: QLB-10tph,QLB-15tph,QLB-20tph,QLB-30tph,QLB-40tph,QLB-60tph,QLB-80tph.
