Name: Napkin Folder Machine (ZYJ-II)
Brand: Jumping
SKU: ZYJ-II

Product name: Napkin Folder Machine
Product introduction:

ZYJ-II Napkin Folder mainly produces top-napkins, obvious embossing and clear printing. There are 1-8 colors to be chosen according the different requirements. It applies the advanced frequency speed control system, automatic positional adjustment, automatic inspection system and a folding machine that has the pushing and holding functions. It features high speed, reasonable structure and convenience operation, steady running and nice outlook. It is the ideal napkin producing equipment.

Technical parameters:
Model	210	230	300	330	400	Other sizes to be ordered
Parent roll width	210mm	230mm	300mm	330mm	400mm
sheet size	(105×105)±2mm 1/4 fold;(105×70)±2mm 1/6 fold	(115×115)±2mm 1/4 fold;(115×80)±2mm 1/6 fold	(150×150)±2mm 1/4 fold;(150×75)±2mm 1/8 fold	(165×165)±2mm 1/4 fold;(165×82.5)±2mm 1/8 fold	(200×200)±2mm 1/4 fold;(200×100)±2mm 1/8 fold
Parent roll	13-20g/ two layers, 23-25 g/ single layer tissue paper
Parent roll diameter	Dia.1200(other sizes to be ordered)
Parent roll core	3(Dia.76mm)(other sizes to be ordered)
Unloading stand	One(other sizes to be ordered)
Tension	Cone pulley manual adjusting or speed regulation hand wheel adjusting
Controlling system	Frequency speed controlling, electric-eye inspecting
Counting device	Pneumatic auto-counting
Installed power	AC380V 50HZ 3-5.5KW(main motor) 0.75(cutting motor)
Folding system	Mechanical folding,ring-shape band saw cutting
Air pressure	0.5Mpa(prepared by the purchaser)
Production speed	120-200m/min(speed differs according to different parent roll)
Optional parts
Embossing device	Steel-to-steel or steel to wool roller
Calendaring device	Steel-to-steel or steel to rubber roller
Printing device	1-8 colors, hectograph printing
Tension controlling system	Automatically
Positional adjustment	Electric or air pressure and hydraulic positional adjustment
