Multimeter (KT8021)
Specifications
- Brand
- KTI ketai instrument
- Origin
- China
- Price Term
- FOB
Multimeter (KT8021) is a Industrial Power Supplies product. Key specs — Brand: KTI ketai instrument; Origin: China; Price Term: FOB.
Product Description
AC/DC Voltage measurement up to 500V
DC Current measurement up to 10A
Resistance measurement up to 200MΩ
Battery Test: 1.5V & 9V
Continuity Check
DC 20KΩ/V AC 9KΩ/V
In according with EN 61010 Standard, CATII 600V
Technical Data:
DC Voltage: 0.1/2.5/25/250/500V
Tolerance: ±(3% full scale)
AC Voltage: 10/50/250/500V
Tolerance: ±(4% full scale)
DC Current: 50μA/5mA/500mA/10A
Tolerance: ±(3% full scale)
Resistance:2k/20k/200k/2M/200MΩ
Tolerance: ±(3% full scale)
Battery Test: 1.5V & 9V
Continuity Check: Buzzer beeps
Diode Test: Test Current approx. 1mA
Test Voltage approx. 2.4V
dB measurement: -10 to 56(0dB: 1mW/600Ω)
Operating Condition: 0-40 at RH<80%
Dimension: 156*102*50mm
Net Weight: 320g incl. battery
