Name: Movable Scissor Lift
Brand: Dalishen
SKU: SJY0.3-4

Movable Scissor lift is a kind of special hydraulic lifter for vertical conveying of automobiles. It is mainly used to carry the automobiles up and down between floors in parking places of various buildings, esp. in low floor buildings. This type of lift table has extensive adaptability, heavy loading capacity, and safe and stable lifting performance.

Movable Scissor lift is also an ideal and economic conveying facility with stable lifting, simple and convenient installation and maintenance, and low electricity consumption. It is suitable for various construction designs without space for motor room.

Name	Model No.	Working Height (m)	Loading Capacity (kg)	Table Size (mm)	External Dimensions (mm)	Net Weight (kg)	Power
Four- wheel Movable Hydraulic Scissor Lift Platform	SJY0.3-4	4	300	1500*750	17009001000	420	380v/2.2kw
	SJY0.3-6	6	300	1500*750	17009001290	650	380v/2.2kw
	SJY0.3-8	8	300	1640*750	18509001390	720	380v/2.2kw
	SJY0.5-8	8	500	1800*1200	230015001410	1300	380v/2.2kw
	SJY0.3-10	10	300	2120*1200	260015001530	1500	380v/2.2kw
	SJY0.5-10	10	500	2120*1200	260015001530	1650	380v/2.2kw
	SJY0.8-10	10	800	2220*1220	280017001740	1960	380v/2.2kw
	SJY0.3-12	12	300	2530*1500	295019501740	2580	380v/2.2kw
	SJY0.5-12	12	500	2550*1500	295019501740	2830	380v/2.2kw
	SJY0.3-14	14	300	2750*1500	325019501970	3100	380v/2.2kw
	SJY0.3-16	16	300	2820*1500	360019802030	3600	380v/2.2kw
	SJY0.3-18	18	300	3700*1500	370019802050	4300	380v/2.2kw
Movable Scissor lifts are flexible to move, and there are several models on different standard. 1. The lifting height of them is from 4m to 18m (4m, 6m, 8m, 10m etc.). 2. Loading capacity: 300kgs, 500kgs, 800kgs, 1000kgs. 3. Types of lifting power: manual, electrical, accumulator and diesel. In special circumstance, the machine will use explosion-proof electric equipment.

Product's Details of Movable Scissor lift

1.The major parameter of this kind of products, such as lifting height, loading capacity, table size, mode of control and speed of lifting, will be designed in accordance with the needs of customers. Or you can entrust our designer to get a reasonable design according to the working circumstance and the use condition

2. This system has various models, so lifting height and loading capacity is also changeful.

3. Mode of control is flexible, using manual device, electrical device and remote control device.

4. The platform will be set up in a pit, and it will be flush with the ground in out-of-service condition, which will not occupy the terrestrial space and not hold up the traffic. It is the human design in all of the lifting devices.
