Monocular handheld IR thermal Imager

SZ105 is a three FOV, top-end handheld IR thermal

imager. Adopting high sensitivity (NETD <50mK), UFPA

detector and variable-focus IR optical system, it ensures

high imaging quality. It also can operate in total darkness,

heavy sand, thick smoke and heavy rain and snow and

other harsh weather. No extra compensation after power

on can quickly detect far target which cannot be found by

man eyes. Lower noise, less bad pixel, excellent non-uniformity

and Mil-STD ensures high performance quality.

Main technical data: 1. Detector: Uncooled long-wave 320×240 2. Focus: 100mm 3. F#:1.2 4. FOV: 6.9×5.2° 5. Operating Range a. Detection Range: ≥1.8km b. Recognition Range: ≥1km c. Monocular OLED display with crisp and sharp clear image, easy operation, stable performance in harsh climate (high/low temperature, rain etc) Functionsa. Brightness & Contrast: manual / automatic controlb. Electric Dual-FOV alternativesc. Electronic Zoom: ×2d. Polarity: White hot / black hote. Offset & Gain Control: Automaticf. Reticle: user-definedg. Command and Control: RS422 / RS232h. Video Output: NTSC / PALi. Sealed, waterproof
