Mast Explorer H15DA - H15DA

Mast Explorer
Rough Terrain Forklifts
Model: 1,5 ton - H15DA
Capacity: 1500Kgs
Drive: 2wd 2x4 or 4wd 4x4
Load Center: 500mm
Engin: Perkins 404c. 15 4cl 36HP
Transmission: Hydrostatic
Two Stage Mast: 2, 7 m = 9. 0 ft
Three Stage Mast: 3, 7m = 12 ft
Intergrated Side shift: Included. Std
Gradability: 35%
Total Weight: 2x4 3000kg = 6614 lb
4x4 3100kg = 6834 lb

A. Total length: 2500mm
B. Axles Distance: 1480mm
C. Load Distance: 420mm
D. Rear Protection: 600mm
E. Ground Clearance: 270mm
F. Total Height: 2000mm
G. Total Width: 1380mm
H Turning Radius: 2x4 2750mm
4x4 3550mm
