Marking machine for Car Fram

It is our smallest marking machine,light weight ,small volume and easy to main machine can work through long cable wire far away from computer and controller,and directly mark on the body,base plate,pillar,engine.The marking-needle is controlled by computer, move on traces as pre-edited characters and graphs, to strike materials at a high frequency under the application of compressed air, finally to form the needed characters and graphs on word-piece.

Main Features: • The machine can be adsorbed to mark on the objects which are in bulk mass and different to move,such as car body,chassis,crossbar,pipe fitting and the machine is in small dimension and light weight,and can work in a long distance from the controller just connected by a long cable wire.• Software with strong editing function support Windows operating system, easy to use, capable to mark Chinese and English characters, Arabic numbers and graphs, automatic marking serial numbers, international standard VIN codes and scales.Applications:Large scale machine power equipment, engine, diesel engine, mechanical, oil and boiler pipe fittings, valve, other spare parts and the work-piece in bulk mass and different to move.

Main tech-specification(Non-standrad products can be customized)Marking Range 150*90mm on plain or the curved surface that radian is less than 3mm

Marking Speed ≤50mm/s(3 or 4 characters, adjustable)

Marking Depth 0.1~1mm adjustable Repeat Precision ±0.01mm

Pneumatic pressure 0.3~0.7Mpa Weight <5kg

Hardness of work-piece HRC≤60 Vlotage 220V

Marking contents Arabic numerals, Common symbols, Chinese character, English letters, graphic, Roman alphabetsAutomatic date printing and automatic production Numbers
