Magnesium Ribbon Anode

Features: The specific process from extrusion, the anode has excellent electrochemical properties flat ribbon shape of the anode, the length can be adjusted, easy to bend. Extruded magnesium anode has a larger area with a mass ratio, thus casting the anode than usual to produce more current.

These features make it unique in cathodic protection engineering applications, especially in long distance pipeline, through the pipelines, large storage pipeline, through the pipe, large storage tanks at the end, lightning and grounding grid used in the composite anode short Yangji and so on.

Magnesium is protected with the main body coil for protection in high resistivity electrolytes steel tank or other structure, or construction of the surface of the narrow space, and high resistivity soil, water and other media. No. Specifications Core diameter(mm) Weight(kg/m) Trademark

A(mm) B(mm) C(mm)

1 19(3/4) 9.5(3/8) 305(1000) 3.4(0.135) 0.395(0.020) Mg-Mn

2 19(3/4) 9.5(3/8) 305(1000) 3.4(0.135) 0.357(0.020) Mg
