METAL/STONE CNC MACHINE JCUT-1212A-C

METAL/STONE CNC RouterJCUT-1212A-C (47''x47'') Applications: Can be used on advertisement engraving, advertisement cutting, stone processing cutting, Cu and Al molding cutting, mold manufacturing cutting, wood processing cutting, wood door manufacturing cutting, craft manufacturing cutting, light box cutting, building mold cutting, indoor decoration cutting, wave board processing cutting, light equipment mold processing cutting, sign and mark manufacturing cutting, Acryl board processing cutting, stamp cutting, and PCB cutting Features: (with trough which used for cooling blades) 1) Machine body: whole cast iron 2) Guideway:cylindrical guideway 3) Driving mode:ball screw 4) Work dimensions: 1,200mm x 1,200mm x 80mm( 5) Body dimensions: 1,500mm x 1600mm x 1,500mm (with bracket) 6) Z-axis working area: 80mm(or 150mm) 7) Max.

Feeding height: 120mm or bigger 8) Cut thickness of material: ≤40mm 9) Max. Speed: 5000mm/min 10) Working speed: 0 - 3,000mm/min 11) Mechanical precision: 0.01mm 12) Software: type 3 software, Artcut software, Artcam software 13) Max.

Power consumption: 1.8kW 14) Power source: AC 220/50/60Hz (or 110v/60HZ) 15) Driver type: stepper motor(XY-85BYG, Z-57BYG motor) 16) Memory: without or (DSP) 17) Spindle: 1.5kW(Ф80mm) variable speed, water cooled motor (or 2.2kW or 3kW,or bigger 18) Spindle speed: 0 - 24,000rpm/min 19) Blade diameter:Ф3.175mm, 4mm,6mm (or 8mm,10mm,12mm, 12.7mm) 20) Control system: (NCSTUDIO) or DSP (USB interface) 21) Command: G code, u00, mmg, plt 22) Running circumstance temperature: 0 - 45°C 23) Relative humidity: 30% - 75% Packing: Pack dimensions: 1,700 x 1700 x 1,600mm Net weight: 600kg (with bracket) Gross weight: 700kg
