MAXDRILL Quarry Drilling Tools

Model Y20 Hand-held Rock Drill is intended for drilling downward and inclined blast holes in medium hard and herd rock (f=8~18):·The rock drill is mainly used small quarries. Mines for constructing in mountain areas, water conservancy works in capital construction, also for secondary blasting in large mines and other projects, Model FY200B Line Oiler is incorporated into for lubricating during operation

—Y24 Hand-held Rock Drill

Most suitable for drilling downward and inclined blast-holes in medium nard and hard rock with a hardness of f=8~18: An ideal tool for rock drilling operations in small open-pit quarries, mines, water conservancy projects and road building in hilly areas, etc, and for secondary blasting in large mines. The incorporation of FY200B Line Oiler with transparent casing provides automatic lubrication during operation during operation.

Grouped control mechanism, quick to start up with〝air-on, water-on, air-off〞 mechanism easy handle and maintain. Low noise, small vibration, energy-saving and efficient, highly interchangeable parts with long service life reliable performance. Different form similar products particularly in its high efficiency, strong flushing and powerful torque

MAXDRILL Quarry Drilling Tools

MAXDRILL can provide you high efficient, low cost and energy economization quarry tools,and we’d like to maximize the satisfactory of the customers

MAXDRILL Diamond Wire Saw

Diamond Wire Saws are available for three major applications:

-- Stationary block sawing

-- Contour wire saw

-- Quarries

There are three diamond wire saw systems for extracting raw blocks from quarries:

-- Diamond wire saw with steel springs

-- Diamond wire saw with plastic coating

-- Diamond wire saw with rubber coating

More specifications is available in PDF file, you can download on the right.

â‘£MAXDRILL Stone Breaking Tools
—

These traditional tools have been used for eons in the stone industry and are still among the most cost-effective tools for splitting stone. Also known as Wedge and Feathers. These tools are the oldest and still one of the best ways to split stone. Small Wedge and shims in 5/8’and 3/4’sizes are good for stone yards or stone masons who want to reduce their rocks to workable sizes 1’,1-1/4’,1-3/8’are for splitting large rocks. Our high quality wedge and features are made for splitting granite and other hard stone.

—

(1) Size: Hex.25mm, Hex.28mm, Hex. 32mm

(2) Length: 400mm-700mm

(3) Shank length: 83mm, 108mm, and 152mm

(4) Head: chisel, point

(5) Package: in wooden case or in bundles.

(6) Productivity: 10000PCS / month
