Listing ID#10059323
CategoryFasteners
Quick answer
Lifting sockets Fixing Inserts is a Fasteners product. Key specs — Origin: china.
Product Description
Primary Competitive Advantages
safe working loads at concrete strnght of 25N/mm²
and High Quality Control
2.factory direct Prices
3.Customer's Design and Logo are Welcome
4.Small Order Acceptable
5.Prompt Delivery
Following Details :
1. Name: lifting sockets with plastic cap
2. Material: seamless precision tube ST37 and stainless tube 304 (A2/1.4301) ,316(A4/1.4571)
3. Surface: Zinc Plated ( yellow and white )
4:packing: carton and wooden pallet
Thread RD | L(mm) | SWL(kg) |
12×1.75 | 40 | 500 |
14×2.0 | 48 | 800 |
16×2.0 | 54 | 1200 |
18×2.5 | 65 | 1600 |
20×2.5 | 69 | 2000 |
24×3.0 | 78 | 2500 |
30×3.5 | 103/105 | 4000 |
36×4.0 | 125 | 6300 |
42×4.5 | 140/145 | 8000 |
52×5.0 | 170/195 | 12500 |
