Laser Engrave And Cutting
Specifications
- Brand
- GStar
- Origin
- wuhan city,China
- Price Term
- FOB
Laser Engrave And Cutting is a Other Plastic & Rubber Machinery product. Key specs — Brand: GStar; Origin: wuhan city,China; Price Term: FOB.
Product Description
Capability Characters
Integrating optics, machinery, electricity, well design; stable structure
High degree automation, control by computer at all
Width breadth, platform which can hoist and fall freely; width arrange for elevation adjusting
Rotary clamp (optional configuration), can engraving on cylinder，cone，camber materials wellApplicable Fields Cutting and engraving nonmetal materials such as woodã€bambooã€Plexiglasã€crystalã€cardboardã€acrylicã€polyester resinã€paperã€leather clothingã€rubberã€plasticsã€stone act .
Technology Index
Speciafications | GS-SE 3525 |
Outline size (mm)(length×width×height) | 880×700×930 1200×700×1030 |
Weight（KG） | ≤50 |
Laser　Power（W） | 40W/60W CO2 / 10WRF / 30WRF |
Lifting distance(mm) | 280 |
Diameter of round material (mm) | ≤ 300 |
Rated Power（W） | 500/1500 |
Maximum engraving size (cm)(length×width) | 300×240 |
Maximum stamp cutting size (mm) (length×width) | 26×22 |
Speed(mm/s) | ≤1200 |
Engraving precision（mm） | 0.025 |
Working environmental temperature（℃） | 5-30 |
Working environmental humidity | ＜68% |
Power supply | AC220V/50HZ ± 5% |
Working environmental requirement | Non-vibrationã€Non-dust〠Non-corroded gas and liquid〠Non-intensity electromagnetic wave |
Optional configuration | Rotary clampã€bamboo clampã€seal clamp |
The above index are for reference , please forgive no notice when some change.
