Listing ID#10050111
ModelPL-11DE
CategoryElectrical Equipment & Supplies
Large brass Wire Drawing with continuous annealing Machine
Specifications
- Brand
- poly
- Origin
- china
- Price Term
- FOB
Quick answer
Large brass Wire Drawing with continuous annealing Machine is a Electrical Equipment & Supplies product. Key specs — Brand: poly; Origin: china; Price Term: FOB.
Product Description
| 　 | Type | PL-11DE |
| 　 | Maximum inlet wire specification (mm) | 8mm H65 brass wire |
| 　 | Complete scope (mm) | 2.6mm-3.2mm |
| 　 | Maximum mechanical speed (m/min) | 500m/min |
| 　 | Volt for annealing (V) | DC 70V |
| 　 | Current for annealing (A) | DC 3000A |
| 　 | Drawing dies no. | 11 |
| 　 | Ratio of mechanical elongation | 0-46% |
| 　 | Power of wire drawing machine (kw) | 110KW |
| 　 | Power of wire receiving machine (kw) | 15KW |
| 　 | Control mode for annealing | Three-phase full wave |
| 　 | Control mode for wire drawing | Gearing control of inlet transducer and PLC |
| 　 | Capacity of wire receving rack | 1500KG Max |
| 　 | Machine dimensions (mm) | 13700×4100×3050 |
| 　 | Weight of machine (kg) | 13000 |
