LED downlight
Specifications
- Brand
- UPLED
- Origin
- CHINA
- Price Term
- FOB
LED downlight is a Lights & Lighting product. Key specs — Brand: UPLED; Origin: CHINA; Price Term: FOB.
Product Description
Working Temperature:-40℃- +50℃
Storage Temperature:-50℃- +80℃
Baffle trim color:Silver,Brass,white,black
Cover:Clear,Frosted diffuser or lens
Voltage:AC100V-240V/DC12V/24V
Life time:50 000hours
Light source:Adopt original Edsion LEDs for high light effciency
Picture | Item NO. | Power | Lumious | Beam Angle | Dimension | Input Voltage | Material |
| UP-D535 | 3X1W | 285lm | 10° 30° 45° 60° | 48XΦ90mm1.9xΦ3.5" | AC100-240V/DC12V | Al+Frosted PC |
3 X 3W | 455lm | ||||||
| UP-D553 | 5 X 1W | 475lm | 30° 45° 60° | 102XΦ105mm 4xΦ4.1" | AC100-240V/DC12V | Al+Frosted PC |
5 X 3W | 746lm | ||||||
| UP-D563 | 6 X 1W | 558lm | 30° 45° 60° | 105XΦ106mm 4.1xΦ4.2" | AC100-240V/DC12V | Al+Frosted PC |
6 X 3W | 855lm | ||||||
| UP-D572 | 7 X 1W | 651lm | 30° 45° 60° | 70XΦ107mm 2.7xΦ4.2" | AC100-240V/DC12V | Al+Frosted PC |
| UP-D5122 | 12 X 1W | 1116lm | 30° 45° 60° | 66XΦ137mm 2.6xΦ5.4" | AC100-240V/DC12V | Al+Frosted PC |
| UP-D5152 | 15 X 1W | 1385lm | 30° 45° 60° | 100XΦ168mm 4xΦ6.6" | AC100-240V/DC12V | Al+Frosted PC |
| UP-D5181 | 18 X 1W | 1635lm | 30° 45° 60° | 100XΦ168mm 4xΦ6.6" | AC100-240V/DC12V | Al+Frosted PC |
Advantage:
Super long life tiem,easy installation and maintenance
Vivid saturated colors without filters
Adopt constant current driver which is 94% efficiency with over-heat protector,can work well in instability voltage.
Special electric circuit save more than 70% energy.
Meet CE / UL safety standards and ROHS environmental protection requirements
Application:
Showcase of shopping mall,hotel, restaurant for indoor decoration lighting
Office, museum Gallery,corridor ,lobby, staircase for spot lighting
Bar,KTV for atmosphere lighting
Jewelry,foods, clothing cabinet
