LED Display Digital is a LED Modules product. Key specs — Brand: Haisheng; Origin: China.
Product Description
Model No:HSGD-O-F-P16 | |
Item | Parameter |
Pitch Pixel | 16 MM |
LED Configuration | 2 R,1G,1B |
LED standard | 5mm Lamp |
Module Dimension | 256*128 MM |
Module Resolution | 16*8 Pixel Dots |
Cabinet Dimension | 1024*768 MM |
Cabinet Resolution | 64*48 Pixel Dots |
Cabinet Weight | 50 KGS/SQ.M |
Luminance | 7000 NIT |
View Angle | 110(H),90(V) Degree |
Power Consumption(Average) | 500 W/ SQ.M |
Best View Distance | 14~125 Meters |
MTTF | 5,000 Hours |
Protection Level | IP 65 |
Pixel Density | 3906 Dots/ SQ.M |
Drive Mode | Static constant current |
The P16 is the most popular models for outdoor media in LED advertising field.It's high resolution for a viewing distance of 16 meters (48 feet) and beyond and its super brightness make it a fantastically vivid demonstration of video, animations and other electronic contents. Our P16 Outdoor is designed to meet this demand in the most thoughtful way.
