LAN Cable UTP Cat.5e Solid, Grey, 24AWG

PRODUCT DESCRIPTION1. This kind of cable use bare copper to be the center conduction with the specification is 24AWG and PE to be the dielectric. The jacket is made of fireproof material, which is so meanful to the Cat.5e communication. 2.

This Cat.5e UTP cable is conform to the SIO/IEC, TIA/EIA and EN standards and the electrical characteristics are exceed the lastest Cat.5e standards. 3. LSZH: means “Low smoke zero halogen”, which is the symbol of environmental protection.ELECTRICAL CHARACTERISTICS1. Impedance: 100±15 2. Static electric capacity: max:17.1nf/kf 3. Resisitance: max:28.6/kf 4.

Unbalance resisitance: max 5% 5. Unbalance capacity: max 330pF/100m 6. Roted communicate rate: 65%PHYSICAL CHARACTERISTICS1. Copper diameter: 24AWG 2. Outer diameter: 5.0mm 3. Weight: 10.5kg/kft 4. Minimum bend radius: O.D.*4-6 5. Maximum pulling tension: 10.0 6. Jacket material: PVC/LSZH 7. Roted temperature: -20~60℃APPLICATION1.

10/100/1000Mbps Ethernet 2. 100VG-AnyLAN 3. Token ring 4. ATM155/ATM622 etcSTANDARD1. ISO/IEC-11801 2. EN-50173 3. TIA/EIA-568BORDERING INFORMATION: Product Code Description Packaging Carton Size GW

SLU5CB241 LAN Cable UTP Cat.5e Solid, Grey, 24AWG 305 m/box 37*37*22 cm 10.25 kg
