Keg washing machine

1.

Technology specification Model QX-1 Size of plate form 510mm×1170mm Height of the plate form 660mm Size of the machine 1250mm×1250mm×2050mm The maximum stroke of the stopcock 300mm Net weight 180kg Capacity 90-120keg/h（20L） Air consumption 8-22.5m3/h (20L) Water consumption 1-3 m3/h (20L) Power 950w Washing type inversion The barrel size Ф250mm-ф500mm H:400mm-660mm 2.

Technology parameter Pressure of the air 0.6-0.8Mpa Pressure of the cylinder 0.4-0.5 Mpa Pressure of the CO2 0.2-0.3Mpa Pressure of the steam 0.2 Mpa Voltage of the electric power AC 220V 50HZ 3. The main framework Frame, control system, solenoid pilot actuated valve, pneumatic element, water flow system etc. 4.

Features This is the cleaning machine of QX-1, the capacity is 120 barrels per hour. It is mainly used in cleaning the plastic beer barrel by the water and the sterile water, equipped with the function of CO2 prepares press.
