JUKI KE-1080 SMT part
Specifications
- Origin
- china
- Price Term
- EX-Work
- Payment Term
- T/T
JUKI KE-1080 SMT part is a Electronic Accessories & Supplies product. Key specs — Origin: china; Price Term: EX-Work; Payment Term: T/T.
Product Description
Origin (0, 0) e Board flow direction B) REF Choose the method of recognition. Shape data recognition (REF=125) is normally used for the board recognition. 1E3C-E-PMB01-A02-00 1.5 Creating the Production Data 2 Editing the board recognition data . When the board recognition of the software switch is disabled, the data cannot be edited. 1.
Click [BoardRecogData] in the main menu. . The sheet on the window opens. 2 Enter the coordinates of board-recognition point A. 3 Click [SelectREF]. . The window opens. 4. Choose the desired REF, shape, and color. Then enter the size, and click [OK]. . The window closes and the sheet opens. 5.
Enter the data of point B by repeating the steps from 2 to 4. . When selecting points AB + Pa and AB +PaPb, enter the data of the points Pa and Pb in the same way. 193C-EPt-EdBr-004 6. Click [Close]. . The screen returns to the main menu. 1B4C-EPt-EdBr-003 Page 1-16 1E3C-E-PMB01-A02-00 1.5.3 Board Positioning Data 1.
About the board positioning data 1.5 Creating the Production Data 1. Y-axis direction clamp operation timing Set the operation timing of the supports and the clamp in fixing the board. By default, “Lower limit” is selected. (Except in the case where the other production-board data is used)
