Iron Melting Induction Furnace 50KG

1.Production Name: Iron Melting Induction Furnace 50KG 2.Production Description: Furnace Model GW-0.05T-100KW/2.5S Rated Capacity T 0.05 Max.

Capacity T 0.06 Rated Power KW 100 MF Frequency KHZ 2.5 Power Input Voltage V 380 MF Output Voltage V 750 Pulse 6 Melting Rate T/H 0.17 Melting Time Minutes/batch 18 Electricity Consumption KWH/T 620 Transformer Capacity KVA 120 Water Cooling Consumption T/H 5 3.Usage: Iron Melting Induction Furnace Mainly used in melting iron, cast iron, grey iron, is with high melting efficiency, good electricity saving effect, good metal component uniformity, less burning loss, speedy temperature rise, easy control of temperature, is suitable to all kinds of metal melting.

4.Characters and Advantages: 1) Constant power output, speedy melting, good electricity saving efficiency. 2) Zero-voltage sweep-frequency style start, adapts to requirement of frequently start.

3) Comprehensive protection functions, such as overcurrency protection, overvoltage protection, current-limiting protection, voltage-limiting, water-break protection, and default protection, equipment runs reliably under premise of melting speed guarantee. 4) Easy to operate, suitable for all casting process. 5) Aluminum Shell, lower in purchase cost. 5.

Package: Plywood cases and nude 6. Min. Order: 1 set 7. Delivery Time:15-30 days 8. Payment Term: 30% DEPOSIT, BALANCE REST BY T/T IN ADVANCE. 9. Offer Technical guide/installation/adjustment
