Name: Insulation Resistance Multimeters
Brand: Uni-Trend
SKU: UT513

SPECIFICATIONS

Basic Functions of Insulation Resistance Multimeters	Range	Best Accuracy
Insulation Resistance	500kW ~ 10GW 1MW*~1000GW	(5%+5)
Low Resistance	1000W	(1%+3)
Testing Voltage	100V/250V/500V/1000V 1000V/1500V/2500V/5000V	0~20%
DC Voltage	1000V	(1%+3)
AC Voltage	750V	(1.5%+3)
Special Functions of Insulation Resistance Multimeters
Auto Ranging
Short Circuit Current		<1.3mA
Data Logging		18
Data Recall
Sleep Mode
Polarization index (PI)
Dielectric Absorption(DAR)
Timer	Within 30 minutes
Compare
Battery Display
Display Backlight	EL
Over Range and High Voltage Warning
USB
Max. Display Analogue Bar Graph	9999

GENERAL CHARACTERISTICS

Power of Insulation Resistance Multimeters	UT511-1.5V Battery (R14) x 8 UT513 -1.5V Alkaline Battery (LR14) x 8
LCD Size	123 mm x 58 mm
Product Color	Grey
Product Net Weight	2kg
Product Size	202 x 155 x 94 mm
Standard Accessories	UT511 - A pair of one plug test lead to one alligator clip, A pair of two plugs test lead to one alligator clip, Batteries, English Manual, Tool Box. UT513 - A pair of one plug test lead to one alligator clip, A pair of two plugs test lead to one alligator clip, Batteries, English Manual, Tool Box, USB Interfac
Optional Accessories*	Power Adapter
Standard Individual Packing	Gift Box
Standard Quantity Per Carton	5 pcs
Standard Carton Measurement	600 x 350 x 320 mm (0.067 CBM Per Standard
Standard Carton Gross Weight	Around 13kg

*Available at Extra Cost
Specifications and other information of Insulation Resistance Multimeters are subject to change without further notice.
