Industrial tablet PC

Display Type

TFT LD 15inch Acoustic Wave Touch Screen

Structure

Aluminum alloy front frame and metal back frame(electrostatic prevention, collision resistance, high heat dispersion

Color

Black

Brightness

250cd/㎡

Resolution

1024*768

Contrast

450:1

Viewing angle

80°/80°(L/R) 80°/80°U/D)

CPU

Intel Dual-Core NM10 1.6G

Main Board

Industrial main board (low power, low consumption, high quality)

System Chipset

IntelD510+NM10/Intel D410+NM10

System Memory

1G/2G (optional)

HDD

250G hard disk

Ethernet

Gigabit Network Interface Card (C.D41T V20)

I/O

1 Power Jack, 1Parallel port, 1 COM

1 VGA port, 4 USB 2.0 ports
1 PS/2 video input, 1 PS/2 keyboard input

1 speaker jack, 1 microphone jack, 1 headphone jack
1 RJ-45 LAN port

Power Input

110V/220V embedded ATX industrial power

Power Output

5A (60W)

Operating Temperature

0℃~45℃

Storage Temperature

-20℃~70℃

Relative Humidity

10-80% relative humidity

Dimension (W*D*H)

37cm*29.5cm*7.2cm

Touch life

50,000,000 time at one point Z-axis response

N.W

6.9kg±0.5kg

G.W

8.0 kg±0.5kg
