IR Lamps with Big Round Ceramic Base

CREATOR produces infrared heat lamps for wide range of applications in coating, plastics, glass, textile printing, photovoltaic industry, PCB industry, food, automobile, etc.

CREATOR IR lamps with different bases, diameters, reflectors and lengths are available for varieties of demands. Our IR heating technology will bring you high performance for your heating and cooling process.



Specification

1.Big round ceramic base IR lamps.

2.Powers are available from 300W to 10000W.

3.CREATOR IR lamps are made of high quality quartz.

4.White reflector is available.

5.Tube diameter is 10MM.

6.The following list is part of our products.

7.We supply custom made IR lamps.



leelyla(at) creatorlighting(at)hotmail.com





Model	Voltage(V)	Wattage(W)	Total Length(MM)	Color Temperature(K)	Leading Wires(MM)	Life(Hour)
QIR220-800W	220	800	655	2450	250	5000
QIR220-1000W	220	1000	515	2450	250	5000
QIR240-1000W	240	1000	655	2450	250	5000
QIR240-1200W	240	1200	655	2450	250	5000
