IR Day/Night Waterproof CCD Camera is a Security product. Key specs — Origin: China (Mainland).
Product Description
TOP-816IR (1/3 Sony 420TVL) TOP-876IR (1/3 Sony 500TVL) TOP-866IR (1/3 Sony 540TVL) Features: Day/Night Weatherproof Camera Series 2.1/3" SONY Color SuperHAD CCD SS11&SS11X&HQ1 Digital signal processor(DSP) 4.allows better picture quality and full function control Resolution 420TVL;500TVL;540TVL Sensitivity:0 Lux(Infrared LED On,at F1.2) 7.Outstanding signal to noise ratio better than 48dB or 50dB 8.Compact function for Shutter/Auto;BLC/Auto;AGC/Auto;Day&Night Function Size,Difference Color Selection 10.15m to 20m Visibility Range at Darkness 11.Dust-Proof/Weather-Proof(IP68),allow immersion in water 12.Front Glass Anti-reflection Design 13.Cable Protection Bracket Design 14.Safety Glass, High Transparency for Light Penetration 15.850nm/940nm(invisible IR light) for selections 16.6.0mm fixed IR lens 17.DC12V 10%
Specifications: 1.)Pick up Device:1/3"SONY SuperHAD Interline Transfer CCD 2.)Signal Format:PAL/NTSC(color) 3.)Picture Elements:PAL:500H*582V NTSC:510H*494V for 420line PAL:752H*582V,NTSC:768H*494V for 500/540line 4.)Horizontal Resolution:420TVL/500TVL/540TVL 5.)Sensitivity:0 Lux at F1.2(Infrared LED On) 6.)Infrared LED:12IR LEDs 7.)Infrared LED Range:About 20m 8.)Scanning System: NTSC:525TVL,2:1 Interlace 9.)Synchronization:Internal sync. 10.)Infrared Spectrum:850 nm/940nm(invisible IR light) for selections 11.)S/N Ratio:more than 50dB(AGC off) 12.)Auto Gain Control:Auto 13.)White Balance:Auto 14.)Electronic Shutter:Up to 1/100,000 sec. 15.)Back Light Compensation:Auto 16.)Video Output:1 Vp-p,75Ω Composite,BNC*1 17.)Lens:6.0mm Lens 18.)Lens Mount:M12*P0.5mm Thread 19.)Power Supply:DC12V 10%,ø 2.0mm DC Jack*1 20.)Power Consumption:230mA 21.)
Dimensions:D45*L63(mm) 22.)Net
Weight:200g 23.)Weatherproof resistance:IP68 24.)Operating
Temperature:-10 ~ +50°C
