Listing ID#10110808
ModelWXK-8A/B/C/D
CategoryHydraulic Tools
Hydraulic Hole Diggers
Specifications
- Brand
- Fivestar Tools
- Origin
- China (Mainland)
Quick answer
Hydraulic Hole Diggers is a Hydraulic Tools product. Key specs — Brand: Fivestar Tools; Origin: China (Mainland).
Product Description
1. Suitable for punching holes on electric switch boxes and metal sheets. Easy to change dies. Make clean punch and cause no damage to the surroundings.
2. Custom punch dies are also available.
3. Please let us know the right dimensions if you want to order square and rectangle dies.
| Model | Tonnage | Max. stroke (mm) | Max.thickness(mm) | Punch range(mm) | Punch dies(mm) | G.W. (Kg) | Volume (cm) | |
| Stainless steel | lron sheet | |||||||
| WXK-8 | 8 | 16 | 1.6 | 3.2 | 16-60 | Φ22 Φ27 Φ34 Φ43 Φ49 Φ60 | 12 | 48×26×13 |
| WXK-8B | 8 | 22 | 1.6 | 3.2 | 16-60 | Φ22 Φ27 Φ34 Φ43 Φ49 Φ60 | 13 | 48×26×13 |
| WXK-8D | 8 | 22 | 1.6 | 3.2 | 16-60 | Φ22 Φ27 Φ34 Φ43 Φ49 Φ60 | 12.5 | 48×26×14 |
| WXK-15 | 12 | 22 | 2 | 4 | 16-114 | Φ63 Φ76 Φ80 Φ89 Φ100 Φ114 | 27 | 48×26×13 |
| WXK-8C | 8 | 22 | 1.6 | 3.2 | 16-60 | Φ22 Φ27 Φ34 Φ43 Φ49 Φ60 | 9 | 50×32×15 |
| WXK-8A | 8 | 20 | 1.6 | 3.2 | 16-60 | Φ22 Φ27 Φ34 Φ43 Φ49 Φ60 | 8 | 43×30×13 |
