Hopper dryer
Specifications
- Brand
- RHONG
- Origin
- china
- Price Term
- FOB
Hopper dryer is a Other Plastic & Rubber Machinery product. Key specs — Brand: RHONG; Origin: china; Price Term: FOB.
Product Description
Features
1. Polished appearance with stainless steel hopper(Adopting the way of spraying plastic on the dryer surface,enduring 200)
wind extending device in high efficiency and distributing evenly so that drying efficiency is improved.
3.Special hot-air winding design,guarantee hot wind sending in a smooth wayin favor of maintenance
internal parts are also made of stainless steel
the hopper body is separable from the bottom part,it is very convenient to clean the hopper so that it is quick to add another material
6.Overheat protection device to reduce the accidents caused by human being or mechnical breakdown
power source switch for safety purpose.(CE standard)
8. Magnetic base with transparent window and normal base are for your choice
Technical Specifications:
Model | Material loading (Kg) | Heat power (KW) | Blower power (W) | Applicable injectors (oz) | Common base (E) | Magnet pad | Automatic timer (AT) | Micro-computer controled with timing performance | Worm-keeping layer (l) | Weight (kg) |
| RDM-12 | 12 | 1.5 | 90 | 1 | 25 | |||||
| RDM-25 | 25 | 3.0 | 90 | 3 | 40 | |||||
| RDM-50 | 50 | 4.0 | 200 | 5-8 | 50 | |||||
| RDM-75 | 75 | 4.0 | 200 | 5-8 | 60 | |||||
| RDM-100 | 100 | 5.5 | 250 | 10-20 | 95 | |||||
| RDM-150 | 150 | 6.0 | 250 | 10-20 | 100 | |||||
| RDM-200 | 200 | 12.0 | 400 | 20-30 | 150 | |||||
| RDM-300 | 300 | 15.0 | 400 | 20-30 | 160 | |||||
| RDM-400 | 400 | 18.0 | 400 | 30-50 | 230 | |||||
| RDM-600 | 600 | 22.0 | 960 | 30-50 | 250 |
| External size | RDM-12 | RDM-25 | RDM-50 | RDM-75 | RDM-100 | RDM-150 | RDM-200 | RDM-300 | RDM-400 | RDM-600 |
| W | 650 | 750 | 850 | 900 | 950 | 950 | 1250 | 1250 | 1350 | 1400 |
| L | 350 | 400 | 500 | 550 | 600 | 600 | 800 | 800 | 900 | 950 |
| H | 750 | 950 | 1100 | 1150 | 1400 | 1700 | 1550 | 1900 | 1900 | 2100 |
Please excuse for not note if some specification of products are changed.
Note
1 is standard allocation,is selection purchase.
2) The are some small difference in quantity due to the different density of various plastics.
3The machine voltage specification is 3380V50Hz.
