Listing ID#10050610
CategoryIntegrated Circuits
Hong Kong UPD16337 - 64-bit AC-PDP Driver
Specifications
- Origin
- Hong Kong
Quick answer
Hong Kong UPD16337 - 64-bit AC-PDP Driver is a Integrated Circuits product. Key specs — Origin: Hong Kong.
Product Description
We offer our 64-bit AC-PDP Driver BSD16337 pin-to-pin compatible with NEC uPD16337 PDP Driver.
BSD16337 is High-voltage AC plasma display panel (PDP) column driver - Supply voltage 4,5-5,5V; - Supply voltage of high voltage drivers 30-130V; - High withstand voltage, high current output (200 V, 400 mA); - Built in four 16-bit bi-directional shift register circuits; - Clock frequency 15MHz; - Wide operating temperature range ( minus 40 to plus 85 C)
