High temperature plate sterilizer
Specifications
- Brand
- LONGWAY
- Origin
- china
High temperature plate sterilizer is a Agriculture & By-product Agents product. Key specs — Brand: LONGWAY; Origin: china.
Product Description
The sterilizer is used for hot filling line
nbsp;
High Temperature
Plate type Pasteurizer
SterilizerThis sterilizer is mainly applicable for processing (sterlizering, insulating and cooling) heat senditive
liquilds, such as fruilt, juice wine and so on.It has charecteristic if high heat efficiency, compact
structure, convenient in operation and maintenance,This sterilizer equips with sanitary pumps tank,
hot water system, temp. controller/recorder and electric control system, all parts, which directly
contact liquid, are made of SUS316, pumps, pneumatic parts and elactric apparayus on the machine
are famouse brands in international market.
Sterilizing temperature: 85-135°C
Outlet temperature: depending one customers’requirement.
Model | Capacity (t/h) | Steam consumption (kg/h) | Steam pressure (kg | Flow (t/h) | Power (kw) | Dimensions (m) | Weight (kg) | Diameter (mm) | ||
Product | Steam | Medium | ||||||||
UHT-3 | 3 | 390 | 6.0 | 9 | 4 | 2.0×1.8×2.0 | 460 | 38 | DN32 | 38 |
UHT-4 | 4 | 520 | 6.0 | 12 | 4 | 2.0×1.8×2.0 | 500 | 38 | DN32 | 38 |
UHT-5 | 5 | 650 | 6.0 | 15 | 5.5 | 2.0×1.8×2.0 | 560 | 38 | DN40 | 38 |
UHT-6 | 6 | 780 | 6.0 | 18 | 5.5 | 2.3×1.8×2.0 | 600 | 51 | DN50 | 51 |
UHT-8 | 8 | 1040 | 6.0 | 24 | 5.5 | 2.3×1.8×2.0 | 720 | 51 | DN50 | 51 |
UHT-10 | 10 | 1300 | 6.0 | 30 | 7.8 | 2.5×1.8×2.0 | 820 | 51 | DN65 | 51 |
UHT-15 | 15 | 1950 | 6.0 | 45 | 10.5 | 2.8×1.8×2.5 | 1620 | 51 | DN80 | 51 |
UHT-20 | 20 | 2400 | 6.0 | 60 | 15 | 3.0×3.0×2.5 | 2500 | 63 | DN100 | 63 |
