H.264 8CH Stand Alone DVR

Features: 1.)H.264 real-time high compression,support dual stream network transmission 2.)Linux Operating System 3.)Graphics & Windows OSD interface 4.)Live view with IE(Internet Explorer),Email alarm supported 5.)Support Remote Mobile Phone Monitoring 6.)Support USB mouse operating 7.)Support D1,HD1 and CIF recording resolution 8.)Full real time record and playback of audio and video 9.)High quality image,brightness,clearness and color are adjustable for each channel 10.)Support image auto sequence switch function 11.)Support recording log function to record happened events 12.)Backup modes:network backup,USB backup Optional 13.)PTZ function via built-in RS-485 port 14.)Support 1 SATA port any size hard disk 15.)Multiplex operation:live display & recording & playback & network monitor at the same time

Specifications: 1.)Compression Format: H.264 2.)Video System: NTSC/PAL 3.)Video Input: Composite 1.0Vp-p/75Ω,BNC*8 4.)Monitor Output: Composite 1.0Vp-p/75Ω,BNC*2 video 5.)VGA Output: Analogue RGB 60Hz 1024*768,800*600,600*480 6.)Resolution: Display NTSC(720*480),PAL(720*576) 7.)Audio Input: -8Db22k Ω,RCA connector*4 8.)Audio Output: -8Db3k Ω,RCA connector*1 9.)Alarm Input: 8channel 10.)Alarm Output: 1channel 11.)PAL:200fps/CIF /NTSC:240fps/CIF 12.)Playback Resolution: NTSC:CIF(352*240),HD1(704*240),D1(704*480) 12.)Occupation Space: All 8CH record at high quality mode:800M/H 13.)HDD

Port: SATA hard disk 14.)Network

Port: 10M/100M Ethernet port 15.)Confidential Function: User and administrator Password Protection 16.)Power Supply: DC:12V/3A 17.)Backup:Network/USB disk/ USB Movable Hard disk/USB DVD ROM 18.)Email:Support email function 19.)Network function: IE browser monitoring/playback and setup/mobile monitoring/email for alarm/DDNS 20.)Power Consumption(without HDD): 20W 21.)Environment: Work Temp:+5 ~ +50℃ Storage Temp:-20 ~ +70℃ 22.)

Dimension:430*390*120mm / 430*390*70mm 23.)

Weight: 3.2kg (without HDD) Remarks: TOP-R527-8V (TOP-R527-8 with VGA)
