Listing ID#10043780
ModelHY-10KW
CategoryElectrical Equipment & Supplies
Quick answer
HY-10KW Wind turbine is a Electrical Equipment & Supplies product. Key specs — Origin: China.
Product Description
| Model | HY-20KW | ||
| Rated power(kw) | 10 | ||
| Maximum power(kw) | 12.5 | ||
| Rotor Diameter(m) | 7.8 | ||
| Rated voltage(V) | DC300V/AC220V | ||
| Rated wind speed(m/s) | 11 | ||
| Starting Wind speed(m/s) | 3 | ||
| Working wind speed(m/s) | 4-25 | ||
| Survived wind speed(m/s) | 50 | ||
| Blades materials | Fiberglass-reinforced plastics | ||
| Rated rotate speed(r/min) | 200 | ||
| Speed regulation method | passitive pitch | ||
| Generator style | 3-phase AC PM | ||
| Tower height(m) | 10(Higher tower can be special made) | ||
| stop method | positive pitch | ||
| main machine weight(kg) | 500 | ||
| Free standing tower weight(kg) | 900 |
