H20 wood beam

Around4.8-5.2kgs per running meter.

Treated by Water Proof Glue. (WBP)

Prefabricated wood H20 beams are manufactured in a range of

sizes. Long lengths use

fingerjoining to splice flanges and butt jointing or toothed

tongue and groove or scarf

configurations to splice the webs. The actual length is

limited only by transportation restrictions

Resistant to rough handling and extreme use with longer

service life. Weight per running meter: 4.8-5.2k kg

Mechanical specification

Bending moment max.5 Kn.m

Cutting action max 10.0KN

Bending max1/500

Live load max 1.5 KN/m2

Length in cm
