Grid LED Display

LED Mesh Screen series can display various vivid video program conveniently, also can display various lighting changing effect designed by professional designer, to show endless charm of art. Numbers of modules can be combined as full color display wall. Controlled by Borcco Studio real time display system, it can display real time video.

The pixels color of modules is pixel by pixel corresponding to that of computer monitor. Color grey scales 4096*4096*4096, and software with function of white balance adjustment and gamma correction, make the color representation more realistic and clear.

LED Mesh Screen series is a novel product which combined with many years experience of LED application and projects, using mordern LED full color display control technic.

LED Mesh Screen with advantages of lightness configuration, easy installation, low cost, suitable brightness, which can be applied in indoor environment such as stage, wine bar, hotel lobby, luxurious top restaurant etc. Also can be installed inside glass wall of building.

With see throught feature, the LED Mesh Screen will transparent mostly normal daylighting come into building.

Technical Features Brightness 1800nitsPixel Pitch 37.5mmPixel type 2R1G1BViewing angel 110degree horizontal & 45degree verticalDimension H600mm x W1200mm x D25mmWeight 3.9KgProtection level IP43 (suitable for indoor used)Transparency 70% for 37.5mm systemColor depth 10 bit per color channelGrey scale(linear) 65536 levels per colourConsumption max.

200W per sq.m.Input singal DVI input 24bit color depth, resolution full HD 1280x1024 pixelsInput voltage AC100-240V 50/60HzOperating temperture -20-50 degree CelsiusMounting system Hanging Fix., tool-free installation
