Germany Zeiss Microscope is a Microscopes product. Key specs — Origin: Germany.
Product Description
Stemi DV4 The Essentials in Focus Overview Stereomicroscopes Model C Stand The Base For Your Modular System Technical Data Greenough Principle Brochure (1.8 MB) The Profile (5.2 MB) EC Declaration of Conformity Stemi DV4 (128 KB) Deutsche Version The innovative advances incorporated in this microscope are obvious not only in the color of the instruments and their compact, original design, but also, and most particularly, in their attractive price - all the result of state-of-the-art production technologies.
Sturdy, hard-wearing technology, the very easy operation of all major function controls and no compromises whatsover in image definition and brilliance - that is the best way to describe this stereomicroscope from Carl Zeiss.
In addition to the four basic models, optionally with a zoom system or adjustable fixed magnifications, the compact Stand C and selected accessories (e. G. Image documentation, darkfield, and many more) are other outstanding features.
The patented zoom system of the Stemi DV4 (Double Lens Vario, zoom factor 4) guarantees high-resolution, brilliant images from overview (8x) to detail (32x). An exceptional feature in this price category: The image remains precisely in focus over the entire zoom range.
The Stemi DV4 SPOT fiber-optic, cold-light illuminator additionally integrated into the microscope body ensures a fully illuminated object field at all times. Weight:5 KG Supplementary lenses 0,3x 0,4x 0,3x...0,5x 0,63x without 1,25x 1,6x 2x Working distance in mm 285 210 234...91 130 92 60 48 31 Magnification 2,4x... 9,6x 3,2x... 12,8x 2,4x...16,0x 5,0x...
20,2x 8,0x... 32,0x 10,0x... 40,0x 12,8x... 51,2x 16,0x... 64,0x Object field In mm 83,3... 20,8 62,5... 15,6 83,3...12,5 40,0... 9,9 25,0... 6,3 20,0... 5,0 15,6... 3,9 12,5... 3,1
