Specification | Input Type | D-Type: DB15 x 2 | Video Input(s) | 8, 16 Cams | Audio Input(s) | 4 Channels , & 16CH(with GV-A16 board) is optional | Recording Rate | 240 fps (NTSC), 200 fps (PAL). | Display Rate | 240 fps (NTSC), 200 fps (PAL). | Video Resolution | NTSC: 720x480, 720x480 de-interlace, 720 x 240,
640 x 480, 640 x 480 de-interlace, 640 x 240, 320 x 240 | pal: 720 x 576, 720 x 576 de-interlace, 720 x 288,
640 x 480, 640 x 480 de-interlace, 640 x 240, 320 x 240 | Compression Format | Wavelet, MPEG-4, GEOMPEG4 | GV-DSP Support | YES | | YES() | GV-NET/IO Card Support | YES | Software | V7.0(with ) / V6.1 / V6.05 | Dimension | D-Type: 198mm x 103mm | NOTE: GV-900 is currently not compatible with via series chipset motherboard. | System requirements | OS Supported | Windows 2000 / Windows XP / Windows 2003 | CPU | Pentium4-2.6 GHZ, 800 MHZ fsb | RAM | 2 x 256MB Dual DDR400 SDRAM (Minimum) | HDD | 120GB Recommended | VGA | NVIDIA Geforce2 MX200 64MB | DirectX | 9.0 or above |
|
|
