Listing ID#10010934
ModelGCPR-G23S
CategoryTelecommunications
GSM Intelligent repeater 23dBm
Specifications
- Origin
- Guangdong,China(Minland)
- Price Term
- FOB
Quick answer
GSM Intelligent repeater 23dBm is a Telecommunications product. Key specs — Origin: Guangdong,China(Minland); Price Term: FOB.
Product Description
| Model Number | GCPR-G23I | |
| Frequency | UL:890-915MHzDL:935-960MHz | |
| Gain | ≥65dB | |
| Automatic Level Control | ≥20dB | |
| Noise Figure | ≤5dB | |
| Gain Flatness | ≤8dB (p-p), | |
| Automatic Gain Control | 30dB in step of 1dB (Auto) | |
| Output Power(Max) | UL≥20±2dBm DL≥23(23)±2dBm | |
| Input Power Range | ≤-25 dBm | |
| IM3 | ≤-45dBc | |
| Spurious Emission | 9KHz~150KHz | ≤-36dBm 1KHz |
| 150KHz~30MHz | ≤-36dBm 10KHz | |
| 30MHz~1GHz (out of band) | ≤ -36dBm 100KHz | |
| 1GHz~6.7GHz | ≤ -36dBm 1MHz | |
| Group Delay | UL≤1μs | |
| Operating voltage | AC 220V | |
