GAS Sterilizer

Scope of Application

1. Medical Supplies:operational instruments, injectors,transfusion system,different kinds of tubes,contraceptive equipment,etc..Medical Appliances:endoscope,heart pacemaker,artificial heart,medical telephone, dialyzer, suction apparatus,etc. 2.Sanitation Articles: Feminine sanitary napkin,disposable dishwares,etc. 3.Medicines of GAS Sterilizer:some Chinese traditional medicines,western medicines,cosmetics. 4.Textile and Biological Products:cotton,woolen and chemical fiber garment,leather, blanket, brush,etc. 5.Instruments and Meters:electronic instruments,optical instruments,telephone sets,etc

Product Features of GAS Sterilizer

product adopts mixed Ethylen Oxide gas, protecting from ignition and exposure,safe and dependable,non corrosive to the sterilizing load ,no pollution to environment . product adopts new technology and features good energy saving and short heating time. 3.Effective sterilization,easy operation. 4.According to the various requirements on sterilization,you can combine the following factors freely: temperature, pressure,sterilization time,residual gas drain times. Main technical Parameters: 1. Sterilization chamber capacity: 30L,60L,130L, 200L, 300L,350L, 500L,600L,800L,1000L. 2.Sterilization temperature:40--65 3.Temperature control precision:+-2 4.Vacuum pressure:0--(-70)KPa. 5.Sterilization hour: 3h control scope: 0--20h. 7.Supply voltage:220v+-10% 50Hz

Structure of sterilizer of GAS Sterilizer: 1. It is vertical case,composed of electric cabinet,sterilization chamber and system control cabinet. 2.Electric cabinet:Its housing is made of A3 board with mainboard installed inside. 3.Sterilization chamber: It is made of high quality stainless steel with 304 mirror board as lining.
