Fully Automatic Plastic Bag Making Machine
Specifications
- Origin
- DongGuan,China.
Fully Automatic Plastic Bag Making Machine is a Other Plastic & Rubber Machinery product. Key specs — Origin: DongGuan,China..
Product Description
This machine has four functions (soft hand bag,Patch bag,rope bag,pre-folded punching bag).It is coupled with machinery,light,electronic,pneumatic integration. Super technology and high-science development contribute to plastic industry a lot.(Only one in domestic)
Type | TF-PBM730 | |
Length of bag-making | 250-750mm | |
Width of bag-making | 250-600mm | |
Pre-folded edge | 50-75mm | |
Bottom-inserted edge | 20-70mm | |
Thickness of film | 0.04-0.1mm | |
Speed of bag-making | Soft hand bag | 60bags/min |
Patch bag | 60bags/min | |
Rope bag | 70bags/min | |
Pre-folded punching bag | 75bags/min | |
Air Compressor | 7HP | |
Power Rating | 11KW | |
Voltage | 220V/380V – 50HZ/60HZ | |
Machine Self Weight | 3500KG | |
Machine dimension | 8200*3100*1870mm | |
