Listing ID#10096656
ModelRXC
CategoryOther Plastic & Rubber Machinery
Full-automatic Plastic Cup Production Line
Specifications
- Brand
- Donglong
- Origin
- CHINA
Quick answer
Full-automatic Plastic Cup Production Line is a Other Plastic & Rubber Machinery product. Key specs — Brand: Donglong; Origin: CHINA.
Product Description
Descriptions of the RXC Full-automatic Plastic Cup Production Line
| Product Name | RXC Full-automatic Plastic Cup Production Line | |
| Descriptions | This RXC Full-automatic Plastic Cup Production Line is formed by Cup Making Machine,Cooling Conveyor and Cup Stacking the plastic sheet(PP,PS,PVC)has been heated to a certain temperature,many kinds of plastic products such as milk cup,soft-drink cup and water cup can be made by the cup making machine. The finished cups then pass the Cooling Converyor to keep its shape and will go to the Stacking Machine for Automatic Packing. | |
| This Line has the advantage of manpower-saving and low cost in Line has a high automation degree,fast in its production automatic stacking of the cups can be done by itself because the forming mould has self-cutting device. | ||
| Range of Sheet | Thickness:0.4-1.6mm(PP,PS,PVC) | |
| Sheet Width | 300-660mm | |
| Forming Area(Max.) | 580×320mm2 | |
| Forming Depth(Max.) | 120mm | |
| Capacity | 20~30suction/min.(adjustable) | |
| Power(Max.) | 70kw,380v,3-phase. | |
| Air Consumption | 2m3/min.(0.6-0.7Mpa) | |
| Range of stacking | Cup Diameter>60mm,Height:Diameter>1.2 | |
| Dimension | Main Machine11000×1800×2500mm | |
| Control Box600×1160×480mm | ||
| Weight About 5000kg | About 5000kg | |
If you are interested in this RXC Full-automatic Plastic Cup Production Line,please feel free to contact us.
