Free Fall Life boat

Free Fall Life boat Free fall lifeboat is the type that embarkation at the aft hatch,its building is according to the latest re angulation of SOLAS and rules of international life saving equipments(LSA),Revision bill of MSC.218(82),MSC.272(85) and resolutions of MSC.81(70),Revision bill of MSC.226(82),MSC.274(85).It can safely evacuate crew from vessels or offshore platforms upon the slipways.The free fall release systems are specifically designed for easy activation by the crew,safe and reliable.

Technical Parameter: Type Main dimension (m) Passenger Permitted height(m) Rating landing angle Host/power(kw) Weigh (kg) Full weight (kg) FC-5.2M 5.20*2.50*3.07 20 16 35° 380J-3/20.6 3JH30A/22.1 DV29/21.3 2615 4265 FF-5,2M 5.20*2.50*3.07 20 16 35° 2955 4605 FC-6.0M 6.00*2.62*3.08 28 16 35° 3182 5492 FF-6.0 6.00*2.62*3.08 28 16 35° 3520 5830 FC-6.8M 6.80*2.75*3.10 32 20 35° 3530 6170 FF-6.8M 6.80*2.75*3.10 32 20 35° 3840 6480 FC-9.0 9.00*2.80*3.33 44 22 35° 4900 8530 FF-9.0M 9.00*2.80*3.33 44 22 35° 5250 8880
