Finger Pulse Oximeter-----CE Approved Manufacturer

CONTEC CE Approved Fingertip Pulse Oximeter Spo2 Monitor
Manufacturer: Contec Medical Systems

Model: CMS 50B Fingertip Oximeter

Features

The device can accurately measure SpO2.
The device will power off automatically if no signal is detected within 5 seconds.
Two AAA size batteries are required for operating, and the continuous working time is 30 hours.
When Low-Voltage Warning is shown on screen, the device maybe not operate normally.
Light and portable, total weight with batteries is about 50g.
Classification: Class II a, (MDD93/42/EEC IX Rule 10)

Technical specifications
A. Display mode:Segment LCD display
SpO2 measuring range: 35%~100%
Pulse rate measuring range: 30bpm~240bpm
Pulse waveform display: bar graph display
Low battery indication: LCD Signal
B. Power supply requirement:
1.5V (AAA size) alkaline batteries × 2
Adaptable range: 2.6V~3.6V
C. Operating current: ≤20mA
D. Resolution: SpO2 : 1%
Pulse Rate : 1bpm
E. Accuracy: SpO2 :70% to 100%±2 digits, below 70% unspecified
Pulse rate:±2 bpm or ±2% (select larger)

F. Measurement at low perfusion:
The values of SpO2 and pulse rate can be displayed properly when pulse saturation is at 0.4%.
Accuracy of SpO2:±4%
Accuracy of Pulse rate:±2bpm or ±2% (select larger)
G. Resistance to surrounding light:
The difference between the value measured in the condition of man-made light and indoor natural light and that of darkroom is less than ±1%.
H. Automatic shutdown function:
The device will power off automatically within 5 seconds when there is no finger in the device.

Contents
1 Main Unit
2 Hanging Belt
3 Pouch
4 User manual

Wattanty

All items are brand new, with 3 years warranty and whole life repair

Certificate

CE & ISO
