FY-3208HA solvent printer is a Outdoor & Hiking Clothing product. Key specs — Origin: china.
Product Description
Model | FY-3208HA | ||
Printhead | Drop on demand Piezo Head(SPT510-35PL) | ||
Mumber of Printhead | 8 Heads | ||
Maximun Print Width | 3,200mm(125.98”) | ||
Print Speed* | 360X360dpi 1Pass 101m2/hr | ||
240X720dpi 2Pass 76m2/hr | |||
240x1080dpi 3Pass 51m2/hr | |||
360x1080dpi 3Pass34m2/hr | |||
720x720dpi 4Pass 26m2/hr | |||
Media | Max.width | 3,300mm(129.92') | |
Max.Weight | 80kg | ||
Type | Frontlit,Backlit,Vinyl,Polyester,Window Film,Mesh,Leather,Backlit Film,Blue Back Paper… | ||
Thickness | 4mm(Max.) | ||
Heating System | 3 way intelligent heater | ||
Auto Media Feeding& Take-up System | Equipped | ||
Ink | Type | Solvent(C,M,Y,K) | |
Capacity | 1L or 5L per Color Main Tank | ||
Auto Cleaning System | Positive Pressure Cleaning,Anti-Clogging Flash Function&Capping System | ||
Print Interface | Optical Fiber | ||
Power Specification | AC 220V/230V 50Hz/60Hz Printing: 660W Heater: 1450W | ||
Operational Environment | Temperature:20°C-28°CHumidity:40%-60% | ||
Compatible RIP Software | Photoprint,UltraPrint,Topaz,Wasatch,Caldera,Maitop | ||
Dimension &Weight | Machine | L4,520mm X W860mm X H1,340mm 398kg | |
Packae | L4,630mm X W880mm X H1,050mm | ||
