Listing ID#10096732
ModelHWS4800
CategoryOther Plastic & Rubber Machinery
FULLY AUTOMATIC SURFACE WlNDlNG MACHlNE
Specifications
- Brand
- Ouhua machine
- Origin
- China
Quick answer
FULLY AUTOMATIC SURFACE WlNDlNG MACHlNE is a Other Plastic & Rubber Machinery product. Key specs — Brand: Ouhua machine; Origin: China.
Product Description
Model No. HWS4800
Roller Width 1800mm,2300mm,3000mm,3600mm, 4200mm,4800mm
Winding Width 1400mm,1900mm,2600mm,3200mm, 3800mm,4400mm
Roll Diameter 600,1000,1200,1500mm
Winding Speed 100,200,400m/min(max.)
This machine can wind up soft films.suitable for use in the production lines of various soft features servo control or variable frequency control system with interface,temperature control of drawing roller and winding roller,simultaneous slitting,auto measuring of wound length,auto severing and change of roll,and real-time display of roll diameter and weight.
