Emi Products

Our foam with conductive fabric layer products include over 200 profile shapes and sizes. Utilizing the highly conductive and corrosion resistant \'\'Flectron\'\' fabric, bonded to low compression foam, products with this foam provide the benefits needed to meet the requirements of today\'\'s electronics.

Specifications: 1) Shielding effectiveness: a) >100dB b) MIL-STD-285 mod 2) Extremely low compression forces: a) Ranging from 5 - 10lbs/ft. b) Allows use of lighter materials and less fastening 3) Low surface resistance: a) b) Provides improved conductivity (ASTM F390) 4) Wide range of flame retardant gaskets available (UL94 V-0 or UL94 HB) 5) Abrasion resistant metallic fabrics show virtually no degradation in shielding performance after 1,000,000 cycles (ASTM 3880) 6) Urethane and thermoplastic elastomer (TPE) cores provide a low compression of 5 - 20% (ASTM D3574) ensuring long-term reliability of gasket performance 7) Service temperatures: -40 ~ 138oC (ASTM D746) 8) Available in nickel/copper (Ni/Cu) to ensure galvanic compatibility with a wide variety of host materials 9) Our versions display no significant performance degradation after environmental exposure per accelerated aging test (ASTM 845)
