Electric wall mounted switch box IP65
Specifications
- Origin
- China
- Price Term
- EX-Work
- Payment Term
- T/T
Electric wall mounted switch box IP65 is a Electronics & Instrument Enclosures product. Key specs — Origin: China; Price Term: EX-Work; Payment Term: T/T.
Product Description
Electric wall mounted switch box IP65 • Protection Level: IP65 • Type: Switch Box • External Size: vast range of sizes • Installation: Surface/flush • Standards: national standards and IEC standards • Technique: powder coating • Material: cold-roll steel, sheet steel, stainless steel Specifications Enclosure box IP 65 1) Body and door manufactured in 1.2/1.5mm sheet steel.
2) Mounting Plate with folded edge in 2.0mm sheet steel. 3) Finished with thermosetting epoxy polyester powder coating. 4) Mounting Plate in smooth finish.
5) IP65 Protection 6) Dimensions of products H W D Thickness(mm) Weight(kg) mm mm mm Door Body M.P N.W G.W 200 200 150 1.2 1.2 2.0 2.39 2.68 250 200 150 1.2 1.2 2.0 2.86 3.17 300 200 150 1.2 1.2 2.0 3.34 3.68 300 200 200 1.2 1.2 2.0 3.81 4.21 300 250 150 1.2 1.2 2.0 3.99 4.39 300 250 200 1.2 1.2 2.0 4.53 4.95 300 250 250 1.2 1.2 2.0 5.02 5.44 300 300 150 1.2 1.2 2.0 4.59 5.16 300 300 200 1.2 1.2 2.0 5.15 5.73 300 300 250 1.2 1.2 2.0 5.71 6.30 We have various door type for reference: • Single metal door • Double metal door
