Electric forklift CPD25J
Listing ID#10210977
CategoryIndustrial Power Supplies
Industrial Power Supplies

Electric forklift CPD25J

Specifications

Origin
China (Mainland)
Price Term
FOB
Request Quote
Quick answer

Electric forklift CPD25J is a Industrial Power Supplies product. Key specs — Origin: China (Mainland); Price Term: FOB.

Product Description

Italian SME Full-AC
  Imported full-AC drive and hydraulic motor
  Imported multifunction LCD instrument
  Turning angle sensor makes the truck travel smoothly and safely when truning

General Model 　 　 CPD25J
Power type 　 　 Battery
Rated capacity 　 kg 2500
Load center 　 mm 500
Dimensions Lift height H mm 3000
Free lift height E mm 140
Fork size mm 1070×120×45
Fork outside spread (Min./Max) 　 mm 240/1040
Mast tilt angle (forward/backward) α/β deg 40704
Overall dimensions Length to fork face L1 mm 2381
Overall width B1 mm 1265
Mast lowered height H1 mm 2040
Mast extended height H3 mm 4240
Overhead guard height H2 mm 2125
Turning radius R mm 2100
Front overhang X mm 464
Min. right angle stacking aisle width 　  mm 3755
RASA
Performance No load/full load Travel speed 　 km/h 40891
Lifting speed 　 mm/sec 300/420
Max. grade ability 　 % 10
Self weight 　 kg 4360
Max. pull force(full load) 　 KN 8
Wheel & Tires Tyres Front 　 mm 23x9-10-16PR
Rear 　 mm 18x7-8-14PR
Tread Front B2 mm 1040
Rear B3 mm 950
Wheelbase A3 mm 1500
Ground clearance(No load / full load) Mast M mm 85/105
Frame F mm 120/140
Power & Control Battery Voltage V 48
Capacity　 Ah 630/700
Motor Drive motor Kw/rpm 8/1300
Hydraulic motor Kw/rpm 15/2200
Controller
