Egypt Light Control

Specifications: Technology parameter: The load of every group : Incandescence lamp 1000W x3 Energy-saving lamp 200W Number of energy-saving lamp 6 pieces, Compact fluorescent twin tube 280W Number of compact fluorescent twin tube 5 pieces Working Ambient Temperature 85 Operation manual: 1.Install 12V battery in the emitter (Inside the packing).

2.Press Key A in any case, Blue wire group + White wire group + Yellow wire group will light up. Press Key B in any case, Blue wire group + White wire group will light up. Press Key C in any case, Blue wire group will light up. Press Key D in any case, the lamps will be turned off.

Switch K (Picture 1) is able to control the lighting up or off of the lamps on the blue wire group of the light fixture.
