EPS Motor ( BMH078-0525 )

â–  Brushless, core, Permanent Magnet
â–  Powerful neodymium magnets, Higher power density
â–  Brushless , high reliability
â–  Low starting voltage
â–  Quick response
â–  Small torque ripple
â–  Low noise
â–  Small size, light weight
â–  Good heat dissipation,low temperature rise
â–  Low vibratory magnitude

Product Specification:

1) Mode Brushless, core, Permanent Magnet
2) Rated Duty S2 3min
3) No Load Speed 2000rpm
4) Rated Voltage DC12V
5) Rated Power 615W
6) Rated Speed 1250rpm
7) Rated torque 4.7N*m
8) Rated Current (effective value of one phase) 72?0% A
9) Terminal Resistance 0.021?0%Ω
10) Torque Constant 0.0478N*m/A
11) Rotation Direction Two-way rotation
12) Insulation grade F
13) IP Rating IP6K9K
14) Noise <48dB

Application: Mainly used for automobile inductry.
