ED6030 Sealing and Shrink Packager
Specifications
- Brand
- E-dynamic
- Origin
- China
- Price Term
- FOB
ED6030 Sealing and Shrink Packager is a Business Services product. Key specs — Brand: E-dynamic; Origin: China; Price Term: FOB.
Product Description
1.Features of ED6030Sealing and Shrink Packager:◆Adopt Upper and lower motor driven conveyor system to facilitate film convey;◆ Thebrand"NORGEN" of Englandair-run control the complete set of working;◆Imported Japan Mitsubishi programmable logic controller (PLC)with stableperformance;◆ Stick-freeTeflon-coated sealing and cutter to ensure clear and stick-free sealing lines.◆Reinforced conveyor motor to ensure steady transportation;◆Adopt German advanced technology, elaborating according to European process.◆ Importedconverter to achieve 0-12m/minsteady speed.
Speed range can be adjustable;◆ Highpower and double fan motor ensure enough circulate wind for cooling.◆Solid conveyor rollers coated with silicon gel to bear heavy objects andminimize damages and wears;◆ Highefficiency cooling system ensure quick formation after heat-shrinking ofproducts;◆ The ED6030 Sealing and ShrinkPackager line integrated by anchor bolts.2.MainTechnical Specifications of ED6030 Sealing and Shrink Packager:Model ED6030
Power Supply 200-240V/50-60Hz
Sealing Size W600mm×H300mm
Working Efficiency 12-18sets/min
Air Pressure 1kpa
Conveyor Width 300mm
Machine Size 210cm×135cm×190cm
Machine Weight 220kg
Tunnel Size 150cm×60cm×30cm
