Dutch weave wire mesh

Material: steel, brass, phosphor bronze wire, etc..

posseses advanced tailoring equipment, so we can offer strips of wire mesh in all kinds of widths, and cut wire mesh into rectangle or square sheets of wire mesh in all kinds of specifications, etc..

Features: stable filtration performance, high precision, high load, well resistance to wear, heat, acid, corrosion, etc.

Uses: Filtering and screening for aerospace, petroleum, chemical, medicine, telecom-communication, scientific research, etc..

Specifications can be customized.

Plain Dutch weave

mesh wire diameter absolute filtration

rate μm nominal filtration

rate μm

8x85 .014x.0126 318 - 340 250 - 255

12x64 .024x.0165 270 - 285 200 - 205

14x88 .020x.013 225 - 245 150 - 155

20x150 .0098x.007 155 - 165 100 - 105

24x100 .015x.010 115 - 125 80 - 85

30x150 .009x.007 95 - 100 65 - 70

40x200 .007x.0055 65 - 70 55 - 60

50x250 .0055x.0045 55 - 60 40 - 45

80x400 .0049x.0028 43 - 48 35 - 40

Twill Dutch weave

mesh wire diameter absolute filtration

rate μm nominal filtration

rate μm

20x250 .0098x.0079 110 - 120 98 - 105

30x360 .0098x.0060 90 - 100 80 - 84

40x560 .0070x.0040 70 - 75 47 - 52

120x400 .0040x.0025 50 - 55 37 - 43

120x160 .0040x.0025 40 - 45 28 - 32

80x700 .0040x.0030 35 - 40 24 - 26

200x600 .0024x.0018 28 - 32 19 - 21

165x800 .0028x.0020 24 - 26 14 - 16

165x1400 .0028x.0016 16 - 18 9 - 11

200x1400 .0028x.0016 12 - 14 5 - 6

250x1400 .0022x.0016 11 - 12 3 - 4

325x2300 .0015x.0010 8 - 9 2 - 3
