Drug Stability Chambers

1. structure using circular air duct design concept, simulate forced convection air circulation principle, specially designed high-power air-circulating fan can generate very high air flow, so that more uniform temperature and humidity, humidity to 20-98% in the range of precise control.

Can achieve efficient and stable test results.(2) Touch screen with large touch screen, configure the intelligent operating system; 32-bit high-performance processors, so simple, more humane.

3 high-precision electronic temperature and humidity sensors for precise measurement of the absolute, electronically controlled humidification and dehumidification system, ROTRONIC electronic humidity sensor even if the frequent replacement of the sample but also to ensure reliable detection of humidity, no maintenance sensor.4 The innovative cooling system with international brand refrigeration compressors and condenser fan EBM Germany, environmentally friendly 134a refrigerant CFC-free, environmentally friendly energy-saving, accurate and effective.5 lighting effects using side lighting design, better completion of the active substance true and real light stability test.6 test holes around the box set dedicated mold of 45mm diameter test holes, user-friendly monitoring.Configure the internal soft silicone plug, ensure that the experiment will not affect the temperature and humidity cabinets.7.RS232 interface to the PC-specific interface, special software CD (for Simplified Chinese Simplified Chinese Windows 2000 or Windows xp operating system) through PC, special software and monitor the preparation of test procedures and save.Directly through a PC dedicated software to display and print test dataapplications: pharmaceutical stability chambers for the pharmaceutical industry, medicine, biotechnology, food industry and other industries, electronics industry, including life sciences, and all the related industries of painstaking research.Features:â—† The product box with the imported CNC machine tools, laser processing technology, outside the box with high-quality cold-rolled plate, the interior of SUS304 stainless steel plate.â—† box around each set of dedicated tooling holes 45mm diameter observation, user-friendly clinical testing.

Within the two plugs with soft silicone.â—† Cabinet insulation using one of Germany Bayer polyurethane foam CFC-free technology, which greatly improves thermal performance, thus greatly reducing energy consumption.Energy than similar products can be more than 30%, the overall strength box.â—† reasonable duct structure in a balanced way the control.Imported special motor and fan to make more uniform distribution of temperature and humidity, greatly improves the temperature and humidity inside the test accuracy and uniformity.â—† The use of international brand refrigeration compressors and condensing the German EBM fan.

Environmentally friendly CFC-free 134a refrigerant, in line with world trends.â—† use large touch screen, configure the operating system of intelligent, high-performance 32-bit processor, so simple, easy programming.â—† Program controlled temperature humidity, microcomputer fuzzy PID control.Temperature time priority, the user can choice.â—† Bottom caster products imported from Japan, the direction of free adjustable and can be locked outside the box with DuPont powder spray.â—† Temperature sensor PT100 use Honeywell products.Humidity sensors used Swiss-Zhuo Nick capacitive sensors.â—† with over-temperature protection, leakage protection, door alarm, power failure alarm, sensor alarm functions.Can greatly improve the safety of use.

Also has automatic start, automatic stop timer is running, the clock display, and calls from the recovery.â—† with R-232 communication interface, USB memory, GPRS remote control alarm.â—† Automatic defrost and manual defrost has two functions for users to choose more suitable for long-term test, the lifting of the user in the use of frost temperature and humidity drift caused serious trouble.Product parameters:convection forced convectioncontrolbalancedtemperature rangewithout illumination -15 ℃ ~ +85 ℃ with light 10 ℃ ~ 85 ℃Humidity control range20 ~ 98% RHTemperature Resolution0.1 ℃Temperature stability 0.1 ℃Temperature uniformity± 1.0 ℃ (65 ℃ pm)degree of humidity fluctuationswithin ± 1.5% (65 ℃ pm)Operating Temperature5 ~ 35 ℃Light intensityadjustable 0-6000LXLux error?

300LXinsulation polyurethane foamprocess controlfuzzy logic PID control normal mode / run modeheated humidification total power1450Wcooling power? Refrigerant245W?

R134awater supply capacitywithin: 10 liters External: 25 litersvoltageAC-220V 50/60HZtray (standard)three-tierperformance parameters under test load conditions: ambient temperature 20 ℃, humidity 50% RH.
