Double Head Laser Cutting Fabrics Machine

Double Head Laser Cutting Fabrics Machine

This equipment equipped with two laser heads, it can auto-distribute cutting array according to the shape or size of designs, ensure automatic processing. Goldenlaser initially innovated two layers auto-feeding system with two laser heads, suitable for processing on two-layers material which the width is below 1600mm, the length is unlimited.

It has the "mirror" function. Compared with single head machine, it improved working efficiency above 4 times, with higher output, lower cost. nbsp Laser type Hermetic and detached CO2 laser tube

Laser power 80W×2 or 100W×2

Working area 1700mm×800mm

Cutting(no-load)speed 0-48000mm/min

Cutting table Vacuum absorb conveyor working table

Repeating location ≤0.15mm

Moving system Step motor control system, offline control

Laser power adjustment Following laser power adjustment

Power supply 220V±5% 50Hz

Format support AI,BMP,PLT,DXF,DST etc

Standard collocation Exhaust fans, Assisted air compressor

Select collocation multilayer auto-feeder syste

JG-17080 Double heads double layers automatical material feeding laser cutting machine
